Products Description
Screw Type Air Cooled Chiller
A screw - type air - cooled chiller is a refrigeration system. It has screw compressors and air - cooled condensers. It has an integrated design and is equipped with reliable brand screw compressors. This ensures durable performance and an efficient cooling effect in demanding refrigeration applications.
The screw chiller uses a screw compressor, which is renowned for its reliability, high - efficiency, and large - capacity cooling performance. It compresses the refrigerant gas, raising its temperature and pressure. As the hot refrigerant gas then passes through the condenser, it releases heat to the surrounding environment. After that, the cooled and condensed refrigerant liquid passes through an expansion valve, where it expands and evaporates, absorbing heat from the coolant fluid (usually water or a glycol - water mixture) that is circulated around the CNC machine components. This cooled coolant is then pumped back to the CNC machine to maintain an optimal operating temperature.
The device is equipped with a "W"-type arranged corrosion-resistant aluminum finned condenser, which has higher energy efficiency compared to traditional models.
Working principle diagram
A water - cooled chiller uses a shell - and - tube evaporator to exchange heat between water and refrigerant. The refrigerant absorbs heat from the process water, producing chilled water. The compressor conveys the heat - carrying refrigerant to the shell - and - tube condenser. Here, the heat is transferred to the condenser water. The heated water is then transported through piping to an external cooling tower. There, the heat is dissipated into the atmosphere. This process is commonly called water cooling.
APPLICATION
This chiller uses air as its cooling medium, which makes it environmentally friendly and eliminates water consumption during operation.
Products Details
|
Item & Description |
Screw Type Air cooled chiller |
|
|
Model |
MG-100A |
|
|
Eavoprator temperature |
-2 degree |
|
|
Condenser temperature |
45 degree |
|
|
Cooling capacity |
Kw |
251KW, 215900kcal |
|
Input power |
kw |
73 |
|
Power supply |
380v/50hz/3ph |
|
|
Refrigerant |
Type |
R407c/R22 |
|
Type of control |
Temperature-sensitive and External Pressure-equalizing Expansion Valve |
|
|
Compressor |
Type |
Semi-hermetic Screw Type |
|
Power |
100HP |
|
|
Qty |
2 |
|
|
Evaporator |
Type |
Internal Thread High Efficiency Shell and Tube heat exchanger |
|
Chilled water flow (m³/h) |
24m³/h |
|
|
Chilled water outlet&inlet |
4' |
|
|
Condenser |
Model |
External Thread shell and tube |
|
Cooling air flow (m3/h) |
108000 |
|
|
Fan power |
0.8*8 |
|
|
Water pump |
KW |
0.75 |
|
Water tank |
L |
90L |
|
Protector |
Safety Protection compressor overheat protection,overflowing protection,high and low pressure protection,anti-frost protection,phrase sequence/open phrase protection and exhaust over heat protection. | |
|
Dimension |
L (mm) |
4700 |
|
W(mm) |
2150 |
|
|
W(mm) |
2150 |
|
|
Set Weight |
kg |
1700 |
| Running Noise | dB(A) | 69 |
Hot- Sale Products
Packing&Shipping
Packing&Shipping
FAQ
Q: I'm unsure how to select the right chiller. Could you assist me in making a choice?
A: Absolutely. Please share a few key parameters, such as the inlet and outlet temperatures you need, cooling time requirements, and operating voltage. We will then recommend the most suitable chiller for your application.
Q: How is the cooling capacity of a chiller determined?
A:The cooling capacity (in kW) can be calculated using the formula:
Cooling Capacity = Flow Rate (m³/h) × Temperature Difference (T1 – T2) ÷ 0.86
Alternatively, the heat load can be calculated as:
Heat Load = Specific Heat × Mass Flow Rate per Hour × Temperature Difference (T1 – T2)
These formulas help in selecting a chiller that meets your process cooling requirements.
Q: How does a chiller system work?
A: A chiller operates through two main cycles: the chilled water circulation loop and the refrigerant circulation loop. Heat absorbed from the process equipment is transferred to the refrigerant circuit, and is then released externally through either air or water cooling.
